Station X-ray Machine for Luggage Parcel Scanner Steel for Security Inspection

Product Description

Product features
  1. Original Hamamatsu detectors, image quality, Omron electrical components.Enhance the overall quality
  2. Global leading parameters: the inspection report issued by the Ministry of Public Security, shows that each parameter is ahead of other products, more details in the inspection report.
  3. Energy-saving design: The machine can sense objects automatically,if there is luggage on the machine will be operating, if there is no luggage,it'll be quiet. (Optional)
  4. One key management: simply rotate the key when clicking shutdown,safe shutdown automatically ,reduce equipment failure.
  5. Environmental-friend Design: lead shade with protective film, prevent lead from hand contact, avoid lead pollution.
  6. Dynamic screen switch: when it is stationary screen it can be switched and when it is dynamic it also can switch freely.
Specification

Technical standardsTechnical parameters
Tunnel size1000(W1000(H)mm
Conveyor speed0.22m/s
Load200 kg
Resolution0.0787 mm
Penetration40 mm
Through resolution0.202mm
Spatial resolutionHorizontal diameter1.0mm,Vertical diameter1.0mm
Conveyor height from the ground620mm
MonitorBenQ 19in LCD Monitor
Storage500G hard drive to save any image in real time, can store more than 100,000 and
can make any image processing, and continuous work to save.
Noise< 55dB(A)
Operating systemwindowsXP
Single check doseOne-time inspection of the X-ray light source irradiation amount 1.5µGy
Leaking radiation dose rateAway from any device outer surface of 5cm, the ray irradiation leak rate should
be < 0.05µGy/H

X-ray Generator
Ray Beam directionTop-illuminated
Tube current0.4~1.25mA(adjustable)
Anode voltage100~160 kV(adjustable)
Angle90°
Generator cooling/working periodsSealed oil bath with forced air/100%
Image performance system
X-ray sensorL type photo-diode array detector(Multi-energy), 12-bit
Monitorhigh resolution 19 inch LCD SamSung monitor
Color quality24-bit real-color
Consolefull package sealed display, connecting cables can be adjusted according
Edge Enhancementobject contour edge is more distinct
Super Image Enhancementimage detail is more distinct
High-penetrate strength displayincrease brightness of dark area in image to display object which is behind high-absorptive mass distinctly
Low-penetrate strength displayincrease contrast of low absorptive mass to display it distinctly
Magnifierfunction of partial enlargement
Brightening/dimmingincrease brightness of image/decrease brightness of image
Image recurrencedisplay previous twenty images and process any one of them
Image restorationrestore image to initial status at the time of stopping conveyor
Image storingreal-time store more than 100,000 images and process it in operating status
Film safetyfor ISO 1600

Multi-energy function
Multi-energy colororange--organic displays, blue--inorganic displays, green--the mixture
High-energy / low-energyswitching display two energy , high-energy display metals, low-energy displays non-metallic
Drugs explosives AuxiliaryAuxiliary detect drugs ,explosives and other dangerous items
Alarm by sounds and lightalarm by sounds and light when conform to condition
Environment
Operating temperature / humidity0ºC~45ºC/20%~95% (non-condensing)
Storage temperature / humidity-20ºC~60ºC/20%~95% (non-condensing)
Voltage90V~250V  50/60Hz
Power consumption1.0KW(max)
Noise level< 55dB (A)

Application

his is a X-ray security product for larger channel size , mainly for large stations, railway stations and other places of security checks, larger parcels ,baggages ,luggage trunk can be detected, so it is widely used in the detection of bulky items.

Our advantage

1.Brands cooperation,ODM,OEM
2.Sales of a complete set of technical solutions
3.Technical guidance and training for customers
4.Product design, technology development, parts processing and sales integration services
5.One of the world's top four brands, leading technology, quality first, service first-class
6.Our security eqipments have Advanced functions, beautiful appearance,adapt to market's need

Company introduction

ARSENAL, an international brand in Europe and America , and one of the world's four leading security brand. USA ARSENALSecurity Group , founded in the mid-century, is now a registered capital of $ 100 million ,headquartered inFlorida,USA , the world 's leading manufacturer of security equipment .

In the 21st century , ARSENAL Hong Kong Security Group introduced into Asia , in 2011 it successfully authorized thefirst Technical Cooperation in mainland - Shenzhen Zhonganxie Technology Co., Ltd. , and signed the cooperation.Zhonganxie Technology Co., Ltd. , the only technical cooperation company in the mainland is a Hong Kong Group operatesUnited States ARSENAL, located in China 's reform and opening special economic zone city - Shenzhen,Zhonganxie iscommitted to the introduction of ARSENAL security brand and its technology , the secondary development,production ,sales and service of high-tech enterprises.

Zhonganxie Technology Co., Ltd mainly in the research, production : metal detectors , X-ray baggage security
screeningequipment , drugs and explosives detectors , fireworks detectors, vehicle visual search and other
securityequipments.Security products includ doors, hazardous liquid detector, underground metal detectors, hand-held metaldetectors, needle machine, food and drug detection instrument, baggage screening machines, vehicle bottom inspectionmirrors and so on. There is one of the four American security brands in the world, USA Arsenal Security Group,to betechnical support ,Zhonganxie Technology has always stood in the forefront of Chinese security manufacturingindustryand become the market leader !

In order to meet the market development , the parties request , Shenzhen Zhonganxie Technology Co., Ltd. the
marketingcenter integrate all resources to make scientific decisions for the brand planning, market operation,
marketing system, standardize management , so as to ensure security, active, efficient, rapid development.

We invite all parties with lofty ideals , guests friends to seek common development , to lead the world's
securitybusiness! We sincerely welcome you to join!

Station X-ray Machine for Luggage Parcel Scanner Steel for Security Inspection
Station X-ray Machine for Luggage Parcel Scanner Steel for Security InspectionStation X-ray Machine for Luggage Parcel Scanner Steel for Security Inspection



Contact us if you need more details on X-ray Baggage Scanner. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Baggage Scanner、Luggage Scanner. If these products fail to match your need, please contact us and we would like to provide relevant information.
