Leakage Radiation Safety X Ray Luggage Scanner for Parcel Inspection Detection System

Product Description

Product features
  1. Original Hamamatsu detectors, image quality, Omron electrical components.Enhance the overall quality
  2. Global leading parameters: the inspection report issued by the Ministry of Public Security, shows that each parameter is ahead of other products, more details in the inspection report.
  3. Energy-saving design: The machine can sense objects automatically,if there is luggage on the machine will be operating, if there is no luggage,it'll be quiet. (Optional)
  4. A key shutdown control: simply rotate the key when clicking shutdown,safe shutdown automaticly ,reduce equipment failure.
  5. Environmental-friendly Design: lead shade with protective film, prevent lead from hand contact, avoid lead pollution.
  6. Dynamic screen switching: when it is stationary screen it can be switched and when it is dynamic it also can switch freely.
X-ray Generator
Ray Beam directionBottom-illuminated
Tube current0.4~0.5mA(adjustable)
Tube voltage100-160 kV(adjustable)
Ray beam divergence angle60°
The cooling / work cycleSealed oil cooling / 100%
Image Processing System
X-ray sensorL-shaped photodiode array detector (C), 24bit depth
Monitorhigh resolution 19 inch LCD SamSung monitor
Color image display24-bit true color display
Edge Enhancementthe outline of objects will be more clear
Super Image Enhancementthe details of the image are more clear
High penetration displayimprove image contrast in bright areas, so the easy penetrating area will be more clear
Low penetration displayimprove image contrast in dark areas, so the difficult penetrating area will be more clear
Magnifierlocal amplification function
Brighten / darkenIncrease/ decrease image brightness
Image pull back / front pullShow the top 20 images, and the current image can be any image processing
Image RestorationRestored to its original state
Image StorageReal-time save any image, any image can be processed arbitrarily ,continuous work to save
Environmental conditions
Operating temperature / humidity0ºC~45ºC/20%~95% (No condensation)
Storage temperature / humidity-20ºC~60ºC/20%~95% (No condensation)
Operating Voltage90V~250V  50/60Hz
Power consumption1.0KW(maximum)
Noise level<55dB (A)
Technical StandardsTechnical Parameters
Tunnel size500(W300(H)mm
Conveyor speed0.22m/s
Load150 kg
Resolution0.0787 mm
Penetration40 mm steel plate
MonitorSamsung 19in LCD Monitor
Storage500G hard drive to save any image in real time, can store more than 100,000 and
can make any image processing, and continuous work to save.
Noise< 55dB(A)
Operating systemwindowsXP
Film SafetySafety to the ISO1600
Leaking radiation dose rateAway from any device outer surface of 5cm, the ray irradiation leak rate should
be < 0.05µGy/H
Dimensions(L) 1750mm (W)750mm(H)1300mm
NW / GW290 kg / 360 kg

Customs, port, prosecutors, prisons, railway stations, courts and other security units.

Our service
1. All products purchased in our company are guaranteed to keep in good repair for three year.
2. If quality problems happen in guarantee period, our company will maintain for free.
3. Additionally, our company provides technical support and fittings for life.
4. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.
5. If you are caught in some problems when using our products, welcome to come to our company anytime.

Company information

ARSENAL, an international brand in Europe and America , and one of the world's four leading security brand. USA ARSENALSecurity Group , founded in the mid-century, is now a registered capital of $ 100 million ,headquartered in Florida,USA , the world 's leading manufacturer of security equipment .

In the 21st century , ARSENAL Hong Kong Security Group introduced into Asia , in 2011 it successfully authorized thefirst Technical Cooperation in mainland - Shenzhen Zhonganxie Technology Co., Ltd. , and signed the cooperation.Zhonganxie Technology Co., Ltd. , the only technical cooperation company in the mainland is a Hong Kong Group operatesUnited States ARSENAL, located in China 's reform and opening special economic zone city - Shenzhen,Zhonganxie iscommitted to the introduction of ARSENAL security brand and its technology , the secondary development,production ,sales and service of high-tech enterprises.

Zhonganxie Technology Co., Ltd mainly in the research, production : metal detectors , X-ray baggage security
screeningequipment , drugs and explosives detectors , fireworks detectors, vehicle visual search and other
securityequipments.Security products includ doors, hazardous liquid detector, underground metal detectors, hand-held metaldetectors, needle machine, food and drug detection instrument, baggage screening machines, vehicle bottom inspectionmirrors and so on. There is one of the four American security brands in the world, USA Arsenal Security Group,to betechnical support ,Zhonganxie Technology has always stood in the forefront of Chinese security manufacturing industryand become the market leader !

In order to meet the market development , the parties request , Shenzhen Zhonganxie Technology Co., Ltd. the
marketingcenter integrate all resources to make scientific decisions for the brand planning, market operation,
marketing system, standardize management , so as to ensure security, active, efficient, rapid development.

We invite all parties with lofty ideals , guests friends to seek common development , to lead the world's
securitybusiness! We sincerely welcome you to join!

Leakage Radiation Safety X Ray Luggage Scanner for Parcel Inspection Detection SystemLeakage Radiation Safety X Ray Luggage Scanner for Parcel Inspection Detection SystemLeakage Radiation Safety X Ray Luggage Scanner for Parcel Inspection Detection System

Contact us if you need more details on Security Scanner. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Baggage Scanner、Luggage Scanner. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : X-Ray Detector
